Description

Chapter 2: Designing Classes with a Single Responsibility

The foundation of an object-oriented system is the message, but the most visible organizational structure is the class

Questions to ask yourself:

• What are your classes?
• How many should you have?
• What behavior will they implement?
• How much do they know about other classes?
• How much of themselves should they expose?

Creating Classes That Have a Single Responsibility

A class should do the smallest possible useful thing; that is, it should have a single responsibility

An Example Application: Bicycles and Gears

• Let's take a look at bikes. Consider the types of gears that bikes use

Small Gears

• easy to pedal, not as fast
• takes many pedals just to make the tires rotate once
• can help you creep along steep hills

Large Gears

• harder to pedal, fast

• sends you flying down those steep hills

• one pedal rotation with your foot might cause the tires to rotate multiple times

• Let's start with a small script and then extrapolate classes out of it:

  Large Gear

  chainring = 52

  cog = 11

  ratio = chainring / cog.to_f

  puts 'Large Gear:'\

  "\n#{chainring}-tooth chainring"\

  "\n#{cog}-tooth cog"\

  "\n#{ratio.round(2)} rotations"

  Small Gear

  chainring = 30

  cog = 27

  ratio = chainring / cog.to_f

  puts "\nSmall Gear:"\

  "\n#{chainring}-tooth chainring"\

  "\n#{cog}-tooth cog"\

  "\n#{ratio.round(2)} rotations"

• Since we're talking about gears, it only makes sense that we start by creating a Gear class based on the behavior above

see 1_gear.rb

• Our Gear class has three methods: chainring, cog, and ratio

• Gear is a subclass of Object and thus inherits many other methods besides the three that we defined

• What I'm trying to say is that the complete set of behavior / the total set of messages to which it can respond is fairly large

• This is great and all - but what if we want to extend the functionality by taking into account the effect of the difference in wheels

  • Bigger wheels travel much farther during each wheel rotation versus smaller wheels

• Consider this formula

  gear inches = wheel diameter × gear ratio

  (where)

  wheel diameter = rim diameter + (2 × tire diameter)

see 2_gear.rb

• This new code is great except our old call to Gear.new(52, 11) no longer works because we added 2 more arguments to our initialize method

Why Single Responsibility matters

• Applications that are easy to change consist of classes that are easy to reuse. [...] A class that has more than one responsibility are difficult to reuse

Determining If a Class Has a Single Responsibility

• How can you tell if your class is only doing a single thing? Try describing what it does in a single sentence. You'll find out very quickly
• Remember that a class should do the smallest possible useful thing
• When we look at our Gear class - perhaps it is doing too much
• We are calculating gear_inches, which is fine - but calculating the tire size seems a little weird

When to Make Design Decisions

• When we look at the Gear class, there's something off about having rim and tire in there.
• Right now the code in Gear is transparent and reasonable - this doesn't mean that we have great design. All it means is that we have no dependencies
• Right now, Gear lies about its responsibilities as it has multiple responsibilities in that it has to do "wheel" calculations in our gear_inches message

Write Code That Embraces Change

Here are some techniques that help you write code that embraces change

Depend on Behavior, Not Data

• Behavior is captured in methods and invoked by sending messages
• Objects also contain data (not just behavior)

Hide Instance Variables

• Always wrap instance variables in accessor methods instead of directly referring to variables, like the ratio method does.

• We can do this by using an attr_reader

  BAD

  def ratio

  @chainring / @cog.to_f

  end

  GOOD

  def ratio

  chainring / cog.to_f

  end

• If your instance variable is referred to multiple times and it suddenly needs to change, you're in for a world of hurt.

• Your method that wraps your instance variable becomes the single source of truth

• One drawback is that because you can wrap any instance variables in methods, its possible to obfuscate the distinction between data and objects

• But the point is that you should be hiding data from yourself.

• Hiding data from yourself protects code from unexpected changes

Hide Data Structures

• Depending on a complicated data structure can also lead to a world of hurt
• For instance, if you create a method that expects the data structure is being passed to it to be an array of arrays with two items in each array - you create a dependency

see 3_obscuring_references.rb

• Ruby makes it easy to separate structure from meaning
• You can use a Ruby Struct class to wrap a structure

see 4_revealing_references.rb

• the diameters method now has no knowledge of the internal structure of the array
• diameters just know that it has to respond to rim and tire and nothing about the data structure
• Knowledge of the incoming array is encapsulated in our wheelify method

Enforce Single Responsibility Everywhere

Extra Extra Responsibilities from Methods

def diameters

  wheels.collect { |wheel| wheel.rim + (wheel.tire * 2) }

end

• this method clearly has two responsibilities

  • iterate over wheels
  • calculate the diameter of each wheel

• we can separate these into two methods that each have their own responsibility

  def diameters

  wheels.collect { |wheel| diameter(wheel) }

  end

  def diameter(wheel)

  wheel.rim + (wheel.tire * 2)

  end

• separating iteration from the action that's being performed on each element is a common case of multiple responsibilities

Finally, the Real Wheel

• New feature request: program should calculate bicycle wheel circumference
• Now we can separate a Wheel class from our Gear class

see 5_gear_and_wheel.rb
